I think someone got it to work, but I can’t find the example.
Here’s an example using Unity.
You may be able to adapt the algorithm below.
List<byte> imageBytes = new List<byte> ();
bool isLoadStart = false; // 画像の頭のバイナリとったかフラグ
byte oldByte = 0; // 1つ前のByteデータを格納する
while( true ) {
byte byteData = reader.ReadByte ();
if (!isLoadStart) {
if (oldByte == 0xFF){
// First binary image
imageBytes.Add(0xFF);
}
if (byteData == 0xD8){
// Second binary image
imageBytes.Add(0xD8);
// I took the head of the image up to the end binary
isLoadStart = true;
}
} else {
// Put the image binaries into an array
imageBytes.Add(byteData);
// if the byte was the end byte
// 0xFF -> 0xD9 case、end byte
if(oldByte == 0xFF && byteData == 0xD9){
// As this is the end byte
// we'll generate the image from the data and can create the texture
// imageBytes are used to reflect the texture
// imageBytes are left empty
// the loop returns the binary image head
isLoadStart = false;
}
}
oldByte = byteData;
}
This guy was working on a Cordova project. I don’t know if he got Live Preview to work.
This might also be helpful:
The guy below got it to work, but did not fully open his code:
From DavidC
the problem is that responseObject is not one image. You receive images continuously while live preview is on. And I was wrong to say that _getLivePreview returns “done” - for this command, it is not a dictionary.
Our code isn’t open sourced but here’s some of it. I have response serializers for both JSON and JPG/MP4 so I can read images and video data.
AFImageResponseSerializer *imageSerializer = [AFImageResponseSerializer serializer];
imageSerializer.acceptableContentTypes = [imageSerializer.acceptableContentTypes setByAddingObject:@"video/mp4"];
NSArray *responseSerializers = @[ [AFJSONResponseSerializer serializer], imageSerializer ];
manager.responseSerializer = [AFCompoundResponseSerializer compoundSerializerWithResponseSerializers:responseSerializers];
Each response contains one or more images (depends on iOS version, I think). So I split the response data by looking for JPG start and end bytes
__block NSMutableData *imageData = [[NSMutableData alloc] init];
[manager setDataTaskDidReceiveResponseBlock:^NSURLSessionResponseDisposition(NSURLSession *session, NSURLSessionDataTask *task, NSURLResponse *response) {
// reset imageData at start of response
[imageData replaceBytesInRange:NSMakeRange(0, imageData.length) withBytes:NULL length:0];
return NSURLSessionResponseAllow;
}];
[manager setDataTaskDidReceiveDataBlock:^(NSURLSession *session, NSURLSessionDataTask *task, NSData *response) {
[imageData appendData:response];
// JPG starts with 0xFFD8 and ends with 0xFFD9
// if imageData contains a complete JPG image
// - extract this JPG data
// - remove JPG data from imageData
// - draw it
// dispatch_async_main(^{
// [self updateLivePreviewImage:[UIImage imageWithData:jpgData]];
// });
}];
camera._getLivePreview is POST, like the others. The response is M-JPEG over HTTP. I don’t know if it returns “done” as well - I had to write all this before the Theta S was released. Even now, it’s not available to buy in the UK :o
I haven’t used HTML5, so I don’t know if an ArrayBufferView can be used for a response that isn’t a fixed size. I also saw a comment about using VIDEO tag for multipart/x-mixed-replace.
This code by gavinovsak saves pictures from the stream to /video
// theta test
var request = require("request");
var MjpegConsumer = require("mjpeg-consumer");
var FileOnWrite = require("file-on-write");
var writer = new FileOnWrite({
path: './video',
ext: '.jpg'
});
var consumer = new MjpegConsumer();
// get session id
var sessionId = '';
request({
method: 'POST',
uri: 'http://192.168.1.1:80/osc/commands/execute',
body: JSON.stringify({
name: "camera.startSession",
parameters: {}
})
}, function (error, response, body) {
if (!error && response.statusCode == 200) {
var result = JSON.parse(body);
sessionId = result.results.sessionId;
console.log(result, result.results.sessionId);
console.log('getting the preview')
request({
method: 'POST',
uri: 'http://192.168.1.1:80/osc/commands/execute',
body: JSON.stringify({
name: "camera._getLivePreview",
parameters: {
"sessionId": sessionId
}
})
}).pipe(consumer).pipe(writer);
} else {
console.log(error, body);
}
});
